Delta Armory M4 / AR15 CQB-R CHARLIE – Black

Delta Armory AR15 CQB-R CHARLIE AEG - Black

The Delta Armory AR15 CQB-R CHARLIE is a compact and versatile M4 AEG airsoft rifle designed for players who need excellent manoeuvrability without compromising reliability. Featuring a lightweight ABS polymer receiver, full RIS quad rail handguard, and reinforced internal components, it is perfectly suited for CQB arenas, urban environments, and fast-paced skirmishes.

Internally, the rifle is equipped with a reinforced Version 2 gearbox capable of handling springs up to approximately M120 for long-term use. Proven internal components include an SHS reinforced piston with 14 full steel teeth, reinforced steel gears with a delayer chip, and durable 7 mm metal sleeve bearings, ensuring dependable performance and long service life.

The 6.03 mm precision inner barrel and rotary hop-up chamber provide excellent accuracy while maintaining stable hop-up adjustment during extended automatic fire. The integrated QRS Gen2 Quick Spring Change System allows rapid spring replacement without opening the gearbox, making it easy to adjust the rifle to different field FPS limits.

Key Features

• Reinforced Version 2 gearbox with QRS Gen2 quick spring change
• SHS reinforced piston with 14 steel teeth
• Steel gears with delayer chip
• 7 mm metal sleeve bearings
• 6.03 mm precision inner barrel
• Rotary adjustable hop-up chamber
• Compact CQB-R configuration
• Durable ABS polymer receiver
• Polymer RIS / Picatinny quad rail handguard
• Modern CNC aluminium trigger
• Retractable Crane-style stock with spacious battery compartment
• 14 mm CCW barrel thread for suppressors and tracer units
• 120-round DMAG Mid-Cap magazine included

Built for Close-Quarters Combat

The compact CQB-R layout offers excellent handling in tight environments while maintaining enough barrel length for consistent outdoor performance. Producing approximately 115 m/s (377 FPS with 0.20g BBs), the rifle performs best with 0.25g–0.28g BBs for improved accuracy and stability.

The CHARLIE series uses traditional mechanical trigger contacts and is designed for 7.4V LiPo or Li-Ion batteries. Players wishing to use 11.1V batteries should install a quality MOSFET or ETU such as the Perun Hybrid V2, JeffTron Leviathan V2, or JeffTron Scylla V2 to protect the trigger contacts and improve electrical reliability.

Package Contents

• Delta Armory AR15 CQB-R CHARLIE AEG Rifle
• DMAG Mid-Cap Magazine (120 BBs)
• 2x RIS Rail Covers

Important Information

• Recommended battery: 7.4V LiPo or Li-Ion.
• Battery and charger are not included.
• A speedloader is required to load the Mid-Cap magazine.
• Regularly clean the inner barrel and maintain the hop-up unit for optimal performance.
• Always wear approved eye protection during use.
• Using an 11.1V battery requires a MOSFET or ETU.
• Use quality M120 springs or lower for maximum gearbox longevity.
• Always disconnect the battery before storing the rifle.

Recommended Accessories

Complete your setup with premium accessories from Airsoftmania:

• Airsoft Rifles
• Airsoft BBs
• Batteries & Chargers
• Tactical Gear
• Delta Armory

Technical Specifications

Model	Delta Armory AR15 CQB-R CHARLIE
Color	Black
Weapon Type	AEG Electric Airsoft Rifle
Variant	CHARLIE
Gearbox	Version 2 QRS Gen2
Quick Spring Change	Yes
Inner Barrel	275 mm × 6.03 mm
Muzzle Velocity	Approx. 115 m/s (377 FPS)
Recommended BB Weight	0.25g–0.28g
Hop-Up	Rotary Adjustable
Bearings	7 mm Metal Sleeve Bearings
Piston	SHS Reinforced (14 Steel Teeth)
Receiver	ABS Polymer
Handguard	RIS / Picatinny Polymer
Thread	14 mm CCW
Magazine Capacity	120 BB Mid-Cap
Battery	7.4V LiPo / Li-Ion (not included)
Connector	Mini Tamiya
MOSFET	No
Weight	2480 g
Length	700–785 mm
